TR-4C

TR-4C; Drake, R.L. (ID = 68898) Amateur

TR-4C; Drake, R.L. (ID = 68899) Amateur

TR-4C; Drake, R.L. (ID = 69000) Amateur

TR-4C; Drake, R.L. (ID = 69001) Amateur

TR-4C; Drake, R.L. (ID = 69002) Amateur
TR-4C; Drake, R.L. (ID = 68735) Amateur TR-4C; Drake, R.L. (ID = 402297) Amateur
TR-4C; Drake, R.L. (ID = 457990) Amateur TR-4C; Drake, R.L. (ID = 457991) Amateur
TR-4C; Drake, R.L. (ID = 496717) Amateur TR-4C; Drake, R.L. (ID = 743213) Amateur
TR-4C; Drake, R.L. (ID = 1371457) Amateur TR-4C; Drake, R.L. (ID = 1371460) Amateur
Use red slider bar for more.
TR-4C; Drake, R.L. (ID = 68735) Amateur
Drake, R.L.: TR-4C [Amateur] ID = 68735 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model TR-4C, Drake, R.L. Miamisburg, Ohio

Country:  United States of America (USA)
Manufacturer / Brand:  Drake, R.L. Miamisburg, Ohio
Year: 1974 Category: Amateur Transmitter/Receiver (and Transceiver)
Valves / Tubes 19: 6EA8 12AV6 6EA8 6EJ7 6BZ6 12BY7A 12BA6 6JB6 6JB6 6JB6 6BZ6 12BA6 12AX7 13DE7 12BA6 6GX6 6AQ5 12AX7 6EV7
Semiconductors (the count is only for transistors) 5:
Main principle Superhet with RF-stage; ZF/IF 9000 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit. / 120; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: TR-4C - Drake, R.L. Miamisburg, Ohio
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 273 x 140 x 365 mm / 10.7 x 5.5 x 14.4 inch
Notes SSB/CW/AM-transceiver for 80-10m HAM-bands, TX-input (supply) 300 watts, TX-output (RF) 100 watts; needs speaker MS-4 with built in power supply AC-4.
Net weight (2.2 lb = 1 kg) 7.2 kg / 15 lb 13.7 oz (15.859 lb)
Price in first year of sale 2'100.00 DM
Collectors' prices
Source of data -- Original-techn. papers.

Model page created by Martin Fichtinger. See "Data change" for further contributors.
