1237

1237; Dual, Gebr. (ID = 290206) R-Player

1237; Dual, Gebr. (ID = 1294592) R-Player

1237; Dual, Gebr. (ID = 1294593) R-Player

1237; Dual, Gebr. (ID = 1294594) R-Player

1237; Dual, Gebr. (ID = 1294595) R-Player

1237; Dual, Gebr. (ID = 1294596) R-Player
1237; Dual, Gebr. (ID = 289485) R-Player 1237; Dual, Gebr. (ID = 289486) R-Player
1237; Dual, Gebr. (ID = 289487) R-Player 1237; Dual, Gebr. (ID = 458136) R-Player
Use red slider bar for more.
1237; Dual, Gebr. (ID = 289485) R-Player
Dual, Gebr.: 1237 [R-Player] ID = 289485 933x526
Select picture or schematic to display from thumbnails on the right and click for download.
For model 1237, Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

Country:  Germany
Manufacturer / Brand:  Dual, Gebr. Steidinger; St. Georgen/Schwarzwald
Year: 1977/1978 Category: Sound/Video Recorder and/or Player
Wave bands - without
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 110-125; 220-240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: 1237 - Dual, Gebr. Steidinger; St.
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 424 x 150 x 368 mm / 16.7 x 5.9 x 14.5 inch
Notes Plattenteller-Drehzahl 33 1/3 und 45 U/min, Tonarm-Aufsetzautomatik mit der Drehzahl-Umschaltung gekoppelt. Auflagekraft: 0-50 mN (0-5 p) stufenlos regelbar. Tonabnehmer abnehmbar, geeignet zur Aufnahme für Tonabnehmer mit Dual-Rasterbefestigung und aller Tonabnehmersysteme mit 1/2"-Befestigung und einem Eigengewicht von 4,5-10 g (inkl. Befestigungsmaterial). Antrieb mit 8-poligem Synchronmotor Pick-up: Ortofon FF 15 D.
Net weight (2.2 lb = 1 kg) 3.8 kg / 8 lb 5.9 oz (8.37 lb)
Source of data Handbuch VDRG 1977/1978
Mentioned in -- Original-techn. papers.

Model page created by Peter Lokowand. See "Data change" for further contributors.



All listed radios etc. from Dual, Gebr. Steidinger; St. Georgen/Schwarzwald
Here you find 859 models, 816 with images and 466 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
