400 Chassis
Dual, Gebr. Steidinger; St. Georgen/Schwarzwald
- Country
- Germany
- Manufacturer / Brand
- Dual, Gebr. Steidinger; St. Georgen/Schwarzwald
- Year
- 1964/1965
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 110615
Q: Dual, Service-Unterlagen
Q: Dual, Service-Unterlagen
Q: Dual, Service-Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 110-125; 150-160; 220-240 Volt
- Loudspeaker
- - For headphones or amp.
- from Radiomuseum.org
- Model: 400 [Chassis] - Dual, Gebr. Steidinger; St.
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 280 x 120 x 205 mm / 11 x 4.7 x 8.1 inch
- Notes
-
Dual 400 Plattenspielerchassis
Moderner Leichtgewichtstonarm (Aluminiumrohr), 4 Geschwindigkeiten, Dual - Stereo-Kristall-System CDS 520/3, Nadel DN3 (55mN), Frequenzbereich 20-16000 Hz, Gleichlauffehler ± 0,25%
- Net weight (2.2 lb = 1 kg)
- 2.2 kg / 4 lb 13.5 oz (4.846 lb)
- Price in first year of sale
- 87.00 DM
- Source of data
- Handbuch VDRG 1964/1965
- Mentioned in
- -- Original-techn. papers. (Serviceanleitung 11/1964)
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
