• Country
• Germany

• Manufacturer / Brand
• Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

• Year
• 1984–1986

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 159869

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 1

• Semiconductors
• BD825

• Wave bands
• - without

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 115/230 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: CS530 - Dual, Gebr. Steidinger; St.

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 440 x 115 x 370 mm / 17.3 x 4.5 x 14.6 inch

• Notes

• Plattenspieler mit Riemenantrieb für 33/45 UpM, Plattenteller-Durchmesser: 305mm, Gewicht 700 Gramm, Liftbedienung über Tasten, Stroboscopüberwachung, Geschwindigkeit manuell justierbar, Netzleistungsaufnahme 1,7Watt

  Magnetsystem Dual ULM 66 E mit Diamantnadel DN 165 E

• Net weight (2.2 lb = 1 kg)
• 3.3 kg / 7 lb 4.3 oz (7.269 lb)

• Author
• Model page created by Museum Roggenhofer. See "Data change" for further contributors.
