CV3; Dual, Gebr. (ID = 600204) Ampl/Mixer
Dual, Gebr.: CV3 [Ampl/Mixer] ID = 600204 398x228
Select picture or schematic to display from thumbnails on the right and click for download.
For model CV3, Dual, Gebr. Steidinger; St. Georgen/Schwarzwald:
ebay 270366136859 Verkäufer pelle-33

Country:  Germany
Manufacturer / Brand:  Dual, Gebr. Steidinger; St. Georgen/Schwarzwald
Year: 1965–1967 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 21:
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 14 W (20 W max.)
from Radiomuseum.org Model: CV3 - Dual, Gebr. Steidinger; St.
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 420 x 108 x 280 mm / 16.5 x 4.3 x 11 inch
Notes

Dual CV 3

Stereo-NF-Verstärker mit 2 Endstufen von je 7 Watt Dauerton- bzw 10 Watt Musikleistung, im Katalog 1966/67 wird dann nur noch 6 Watt Dauerton angegeben.

Übertragungsbereich: 20 - 20.000 Hz.

Eingebauter Vorverstärker für Magnetsysteme.

Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Price in first year of sale 455.00 DM
Collectors' prices
Source of data Handbuch VDRG 1966/1967
Mentioned in -- Original-techn. papers. (Dual Phonogeräte 1965/66, 1966/67, Serviceanleitung 1966, Bedienungsanleitung 1965)

Model page created by Wolfgang Winkler. See "Data change" for further contributors.
