Hi-Fi 3-Weg Box CL45-1

Hi-Fi 3-Weg Box CL45-1; Dual, Gebr. (ID = 1880976) Speaker-P

Hi-Fi 3-Weg Box CL45-1; Dual, Gebr. (ID = 1880977) Speaker-P
Hi-Fi 3-Weg Box CL45-1; Dual, Gebr. (ID = 1621208) Speaker-P Hi-Fi 3-Weg Box CL45-1; Dual, Gebr. (ID = 1621209) Speaker-P
Hi-Fi 3-Weg Box CL45-1; Dual, Gebr. (ID = 1621210) Speaker-P Hi-Fi 3-Weg Box CL45-1; Dual, Gebr. (ID = 1621211) Speaker-P
Hi-Fi 3-Weg Box CL45-1; Dual, Gebr. (ID = 1621212) Speaker-P Hi-Fi 3-Weg Box CL45-1; Dual, Gebr. (ID = 1620941) Speaker-P
Use red slider bar for more.
Hi-Fi 3-Weg Box CL45-1; Dual, Gebr. (ID = 1621208) Speaker-P
Dual, Gebr.: Hi-Fi 3-Weg Box CL45-1 [Speaker-P] ID = 1621208 677x900
Select picture or schematic to display from thumbnails on the right and click for download.
For model Hi-Fi 3-Weg Box CL45-1, Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

Country:  Germany
Manufacturer / Brand:  Dual, Gebr. Steidinger; St. Georgen/Schwarzwald
Year: 1985 ? Category: Loudspeaker, headphone or earphone
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Hi-Fi 3-Weg Box CL45-1 - Dual, Gebr. Steidinger; St.
Material Wooden case
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 280 x 405 x 200 mm / 11 x 15.9 x 7.9 inch
Notes

Das Modell CL 45-1 von Dual ist eine 3-Weg Lautsprecherbox -
(1 Tiefton- 1 Mittelton- und 1 Hochton-Lautsprecher).
Lautsprecher-Abdeckung mit Stoff-Bespannung;
4 m Anschlusskabel mit DIN-Stecker.

Frequenzbereich, 40 - 16.000 Hz
Nenn- /Musikbelastbarkeit, 40/60 Watt;
Impedanz, 8 Ohm.

Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)

Model page created by Jürgen Küting. See "Data change" for further contributors.
