For model RR3404 "Paniere" Ch= RR3404.5, Ducati, SSR (Società Scientifica Radio Brevetti Ducati); Bologna

Country:  Italy
Manufacturer / Brand:  Ducati, SSR (Società Scientifica Radio Brevetti Ducati); Bologna
Year: 1940 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6V6 6Q7 6K7 6A8 5Y3
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 125, 160, 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 3 W (unknown quality)
from Radiomuseum.org Model: RR3404 "Paniere" Ch= RR3404.5 - Ducati, SSR Società
Material Wooden case
Shape Design Radio or Novelty / Gadget - fancy or unusual shape.
Dimensions (WHD) 440 x 320 x 330 mm / 17.3 x 12.6 x 13 inch
Notes Riceve OM da 600 a 1500 Khz; OC da 6 a 11 Mhz; OCC da 12 a 19 Mhz. Mobile in pero. Potenza d'uscita: 3 W. Consumo: 60 W.
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Collectors' prices
Source of data Guida Pratica Antique Radio (1) 1999
Mentioned in Il museo della radio; Primo Boselli; 1992 (Antique Radio Magazine - Anno X - n. 59 - febbraio 2003)
Literature/Schematics (1) Il Radio Libro, (Ravalico) 8.Ed. (.)

Model page created by Alessandro De Poi. See "Data change" for further contributors.
