For model C7, Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris:
F; Ducretet (-Thomson); Paris; Model C7 - 1

Country:  France
Manufacturer / Brand:  Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris
alternative name

SED
Year: 1932/1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 35 27 24 35 27 47 80
Semiconductors (the count is only for transistors) unknown_ballast
Main principle Superhet with RF-stage; ZF/IF 109 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 115; 130; 150; 170; 225; 250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: C7 - Ducretet -Thomson; avant:
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 330 x 450 x 270 mm / 13 x 17.7 x 10.6 inch
Notes

Commande unique. Étage HF. HP électrodynamique Thomson. Utilise une régulatrice.

Net weight (2.2 lb = 1 kg) 17 kg / 37 lb 7.1 oz (37.445 lb)
Price in first year of sale 2,990.00 FRF
Collectors' prices
External source of data Serge Laffont/Martin Renoth
Mentioned in -- Original prospect or advert
Literature/Schematics (1) Schémathèque Toute la Radio (STR) (No. 246)
Literature/Schematics (2) Le Guide du Collectionneur TSF Biraud/Foster, Vol. I (page 162)
