• Year
  • 1934/1935
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 104120
    • alternative name: SED

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superhet with RF-stage
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 100-125; 120-140; 137-160; 205-245; 225-260 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: C805 - Ducretet -Thomson; avant:
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 530 x 420 x 300 mm / 20.9 x 16.5 x 11.8 inch
  • Notes
  • 3 gammes d'ondes : TPO (très PO = OC) de 18 à 6 mc, PO de 1500 à 550 kc, GO de 350 à 150 kc. Sélectivité 9 kc. Antifading. Châssis semblabe à celui du C75.

    Modèle spécial pour 25 périodes.

    Double changement de fréquence avec deuxième 6A7 pour ondes courtes de 19 à 50 m. Voir documentation technique pour l'emploi des organes de commande pour la réception en OC.

    Voir aussi C805 nouveau modèle sans double changement de fréquence, avec commutateur PO-GO/OC à l'arrière du châssis.

  • Price in first year of sale
  • 3,700.00 FRF
  • Mentioned in
  • -- Original prospect or advert (Le Journal, 28.01.1935)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by John Koster. See "Data change" for further contributors.
