D2926 Modèle 2 (UCH42)

D2926; Ducretet -Thomson; (ID = 1851819) Radio
D2926; Ducretet -Thomson; (ID = 1851820) Radio
D2926; Ducretet -Thomson; (ID = 1851821) Radio
D2926; Ducretet -Thomson; (ID = 1851823) Radio
D2926; Ducretet -Thomson; (ID = 1851824) Radio
D2926; Ducretet -Thomson; (ID = 1851825) Radio
D2926; Ducretet -Thomson; (ID = 1851826) Radio
D2926; Ducretet -Thomson; (ID = 1851857) Radio
Use red slider bar for more.
D2926; Ducretet -Thomson; (ID = 1851857) Radio
Ducretet -Thomson;: D2926 [Radio] ID = 1851857 935x733
Select picture or schematic to display from thumbnails on the right and click for download.
For model D2926 Modèle 2 (UCH42), Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris:
Photo issue de la documentation technique Ducretet Thomson
Country:  France
Manufacturer / Brand:  Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris
alternative name
Year: 1949/1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UF41 UAF42 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 472 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Power type and voltage AC/DC-set / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out
from Model: D2926 [Modèle 2 ] - Ducretet -Thomson; avant:
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 388 x 270 x 200 mm / 15.3 x 10.6 x 7.9 inch

Il existe un modèle 1 avec UCH41.

Attention châssis relié au secteur !

Net weight (2.2 lb = 1 kg) 6.4 kg / 14 lb 1.6 oz (14.097 lb)
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Le grand livre de la TSF (fiche 8824)

Model page created by Dirk Bladt. See "Data change" for further contributors.
