D3923 Tube UBC41

D3923; Ducretet -Thomson; (ID = 211889) Radio

D3923; Ducretet -Thomson; (ID = 1196783) Radio

D3923; Ducretet -Thomson; (ID = 1196781) Radio
D3923; Ducretet -Thomson; (ID = 60532) Radio D3923; Ducretet -Thomson; (ID = 160617) Radio
D3923; Ducretet -Thomson; (ID = 160620) Radio D3923; Ducretet -Thomson; (ID = 160619) Radio
D3923; Ducretet -Thomson; (ID = 451107) Radio D3923; Ducretet -Thomson; (ID = 451108) Radio
D3923; Ducretet -Thomson; (ID = 451109) Radio D3923; Ducretet -Thomson; (ID = 451110) Radio
D3923; Ducretet -Thomson; (ID = 899991) Radio D3923; Ducretet -Thomson; (ID = 1932208) Radio
Use red slider bar for more.
D3923; Ducretet -Thomson; (ID = 60532) Radio
Ducretet -Thomson;: D3923 [Radio] ID = 60532 500x401
Select picture or schematic to display from thumbnails on the right and click for download.
For model D3923 Tube UBC41, Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris:
Ducretet D3923 (1952) Copy from Ebay

Country:  France
Manufacturer / Brand:  Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris
alternative name

SED
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UF41 UBC41 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 472 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 115 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: D3923 [Tube UBC41] - Ducretet -Thomson; avant:
Material Moulded (Bakelite or Plastics)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 180 x 130 x 130 mm / 7.1 x 5.1 x 5.1 inch
Price in first year of sale 15'050.00 FRF
External source of data Serge Laffont/Martin Renoth
Literature/Schematics (1) Radio Constructeur et Dépanneur 1951


All listed radios etc. from Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris
Here you find 616 models, 470 with images and 255 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
