- Country
- France
- Manufacturer / Brand
- Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris
- Year
- 1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 105770
-
- alternative name: SED
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 472 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 3 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: L036 - Ducretet -Thomson; avant:
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 600 x 354 x 260 mm / 23.6 x 13.9 x 10.2 inch
- Notes
-
Equipé d'un phono, la référence est LP036
Gamme chalutier par adjonction d'un bloc HF auxiliaire sur la face arrière du chassis couvrant la gamme de 69 à 190 mètres
HP elliptique 16 x 24 cm.
- Source of data
- Le grand livre de la TSF
- Author
- Model page created by John Koster. See "Data change" for further contributors.
