For model L2323, Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris

Country:  France
Manufacturer / Brand:  Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris
alternative name

SED
Year: 1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AT6 50B5 35W4
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage AC/DC-set / 110/130 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: L2323 - Ducretet -Thomson; avant:
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 220 x 160 x 140 mm / 8.7 x 6.3 x 5.5 inch
Notes

Separate unit for 220 V. Colours: ivory, green, blue.

Dial lamp: 6,5V/0,1A.

External source of data Serge Laffont/Martin Renoth
Source of data Le grand livre de la TSF


All listed radios etc. from Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris
Here you find 617 models, 472 with images and 255 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Ducretet -Thomson;: L2323
Threads: 1 | Posts: 1
Hits: 1497     Replies: 0
ducretet: L2323;
Ildefonso Angel López
26.Sep.13
  1

Tengo dos Radios Ducretet L2323 y las valvulas 35w4 y 50b5 estan montadas en diferente posicion

segun esquema.

Donde el esquema dice 35w4 esta montada la 50b5

Donde el esquema dice 50b5 esta montada la 35w4

Las radios funcionan perfectamente

Un Saludo
