L3D

L3D; Dux Radio AB; (ID = 2310410) Radio L3D; Dux Radio AB; (ID = 2310411) Radio
L3D; Dux Radio AB; (ID = 2310412) Radio L3D; Dux Radio AB; (ID = 2310413) Radio
L3D; Dux Radio AB; (ID = 2310414) Radio L3D; Dux Radio AB; (ID = 2310415) Radio
Use red slider bar for more.
L3D; Dux Radio AB; (ID = 2310410) Radio
Dux Radio AB;: L3D [Radio] ID = 2310410 1400x1410
Select picture or schematic to display from thumbnails on the right and click for download.
For model L3D, Dux Radio AB; Stockholm:
Image taken from polish online auction portal .allegro.pl. Auction number: 7532151163

Country:  Sweden
Manufacturer / Brand:  Dux Radio AB; Stockholm
Year: 1931 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3:
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Direct Current supply (DC) / 220 Volt
Loudspeaker Magnetic loudspeaker (reed) generic.
Power out
from Radiomuseum.org Model: L3D - Dux Radio AB; Stockholm
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).

Model page created by Tomasz Szczesniak. See "Data change" for further contributors.



All listed radios etc. from Dux Radio AB; Stockholm
Here you find 166 models, 148 with images and 76 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
