V64; Dux Radio AB; (ID = 665992) Radio
Dux Radio AB;: V64 [Radio] ID = 665992 410x515
Select picture or schematic to display from thumbnails on the right and click for download.
For model V64, Dux Radio AB; Stockholm:
Courtesy .skanesauktionsverk.se

Country:  Sweden
Manufacturer / Brand:  Dux Radio AB; Stockholm
Year: 1935–1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: AK1 AF2 AB1 E446 E443H 506
Main principle Superheterodyne (common); ZF/IF 115 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-260 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out 3.1 W (unknown quality)
from Radiomuseum.org Model: V64 - Dux Radio AB; Stockholm
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Notes El esquema es idéntico al modelo 525A de Philips. Super Octodo.
Price in first year of sale 285.00 SEK
Mentioned in -- Original prospect or advert (Radio och Radioamatören 8/1935)

Model page created by a member from E. See "Data change" for further contributors.



All listed radios etc. from Dux Radio AB; Stockholm
Here you find 168 models, 152 with images and 76 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
