Dynacord W.: Eminent EMT [Ampl/Mixer] ID = 2388105 1400x507

Select picture or schematic to display from thumbnails on the right and click for download.

For model Eminent EMT, Dynacord (W. Pinternagel); Straubing

Country:

Germany

Manufacturer / Brand:

Dynacord (W. Pinternagel); Straubing

Year: 1962–1965

Category: Audio Amplifier or -mixer

Valves / Tubes

9: ECC83 ECC83 ECC83 ECC83 EM84 ECC83 EL34 EL34 GZ34

Main principle	to an article Audio-Amplification
Wave bands	- without
Details
Power type and voltage	Alternating Current supply (AC) / 110, 130, 220, 240 Volt
Loudspeaker	- This model requires external speaker(s).
Power out
from Radiomuseum.org	Model: Eminent EMT - Dynacord W. Pinternagel;
Material	Metal case
Shape	Book-shelf unit.
Dimensions (WHD)	375 x 115 x 277 mm / 14.8 x 4.5 x 10.9 inch
Notes	Erstes Modell aus der EMINENT-Serie. 4 Vorverstärker, 2 Pegelverstärker, eine Phasenunkehrstufe, eine Gegentaktendstufe. 5 Eingänge, davon 4 mischbar. Leistungsanzeige mit magischem Band.
Net weight (2.2 lb = 1 kg)	12.5 kg / 27 lb 8.5 oz (27.533 lb)
Price in first year of sale	540.00 DM
Source of data	Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1)	Mütron-Katalog 1963

Model page created by Peter Böhm. See "Data change" for further contributors.

All listed radios etc. from Dynacord (W. Pinternagel); Straubing
Here you find 197 models, 172 with images and 87 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.

Collection of Peter Böhm (D)

Collection of Tobias Münzing (D)

Collection of Hannes Gerber (D)

Collection of Jürgen Küting (D)

Forum contributions about this model

Dynacord W.: Eminent EMT

Threads: 1 | Posts: 2

Hits: 7464 Replies: 1

dynacord: Eminent (EMT) Wirklich mit EL84 und nicht EL34

Alexander Schmitz
22.Feb.06

dynacord: Eminent (EMT) Wirklich mit EL84 und nicht EL34

Hallo,

Ich habe einen solchen Verstärker vom Schrott bekommen. Jedoch arbeitet meiner nicht mit EL84 wie angegeben, sondern mit EL34. Handelt es sich um einen Fehlerhaften Eintrag im Radiomuseum, oder handelt es sich bei meinem Gerät um einen anderen Verstärker?

Franz-Josef Haffner
22.Feb.06

No subject

bei http://www.albertkreuzer.com sind 2x EL34 angegeben. Albert Kreuzer hat auch einen Schaltplan professionell raugezeichnet den man dort downloaden kann. Im Hauptmenü auf die Schaltfläche "Deutsch" klicken und dann runterscrollen auf:

12/18/02 Dynacord Eminent from the sixties lives again! With pictures and schematic

Das schliesst allerdings nicht aus das es evtl. auch eine Variante mit 2x EL84 gegeben hat.

Gruß,
Franz-Josef
