• Country
• Germany

• Manufacturer / Brand
• Dynacord (W. Pinternagel); Straubing

• Year
• 1960

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 103036

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• ECC83 ECL86 ECL86

• Number of Transistors

• Semiconductors
• B250C125

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 160; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm

• Power out
• 12 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: KV12 - Dynacord W. Pinternagel;

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 320 x 410 x 260 mm / 12.6 x 16.1 x 10.2 inch

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Price in first year of sale
• 395.00 DM

• Source of data
• -- Collector info (Sammler)

• Mentioned in
• Funk-Technik (FT) (15/1960, S. 556 / Neuvorstellung Messe Hannover)

• Literature/Schematics (1)
• -- Original-techn. papers. (Zusatz, Technische Daten)

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
