442UT; Echo; Budapest (ID = 407357) Radio
Echo; Budapest: 442UT [Radio] ID = 407357 444x283
Select picture or schematic to display from thumbnails on the right and click for download.
For model 442UT, Echo; Budapest

Country:  Hungary
Manufacturer / Brand:  Echo; Budapest
Year: 1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: DK21 DF21 DAC21 DL21 CL6 CY2
Main principle Superheterodyne (common)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Line / Batteries (any type) / 220 / 1,4 & 90 Volt
Loudspeaker Presumably Dynamic Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 442UT - Echo; Budapest
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 615 x 300 x 340 mm / 24.2 x 11.8 x 13.4 inch

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.



All listed radios etc. from Echo; Budapest
Here you find 34 models, 28 with images and 32 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.





Forum contributions about this model
Echo; Budapest: 442UT
Threads: 1 | Posts: 1
Hits: 221     Replies: 0
echo: Bilder und Röhrenbestückung
Florian Henkel
28.May.21
  1

Bei diesem Modell ist mir aufgefallen, dass bei 4 Abbildungen eine Anzeigeröhre oben neben der Skala zu sehn ist. Das passt nicht zum Bestückungsplan und den aufgeführten Röhren.

Mit der Bitte um Überprüfung

Florian Henkel
