• Country
• Germany

• Manufacturer / Brand
• Echolette (Marke / brand); München

• Year
• 1966 ?

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 289558

• • Brand: Klemt-Echolette

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• ECC83 EL500 EL500

• Number of Transistors
• 1

• Semiconductors
• BC113 or. BFY39 B380C600

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Guitar Amplifier

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 35 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Echolette B35 - Echolette Marke / brand;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 450 x 185 x 240 mm / 17.7 x 7.3 x 9.4 inch

• Notes

• Bass- und Gitarrenverstärker. Augangsimpedanz umschaltbar 6 Ω oder 15 Ω.

  Unterschied zum Modell Echolette B30:

  • Gegentakt-B-Endstufe, feste Gittervorspannung (Bias) der Endstufe (einstellbar).
  • Andere Versorgung der Endstufen-Schirmgitter über Vorwiderstand.

  ---

  Haut parleur 6 ohms ou 15 ohms

  Différences par rapport au B30: polarisation grilles EL500 fixe (mais réglable) et tension d' écran par résistance chutrice.

• Net weight (2.2 lb = 1 kg)
• 8.5 kg / 18 lb 11.6 oz (18.722 lb)

• Literature/Schematics (2)
• -- Schematic

• Author
• Model page created by Klaus Kohler. See "Data change" for further contributors.
