Monarch BKL

Monarch BKL; Eclipse Radio Pty. (ID = 802528) Radio

Monarch BKL; Eclipse Radio Pty. (ID = 802529) Radio
Monarch BKL; Eclipse Radio Pty. (ID = 2313633) Radio Monarch BKL; Eclipse Radio Pty. (ID = 1695895) Radio
Monarch BKL; Eclipse Radio Pty. (ID = 1695897) Radio Monarch BKL; Eclipse Radio Pty. (ID = 1695896) Radio
Monarch BKL; Eclipse Radio Pty. (ID = 1695898) Radio Monarch BKL; Eclipse Radio Pty. (ID = 1695899) Radio
Monarch BKL; Eclipse Radio Pty. (ID = 1695900) Radio Monarch BKL; Eclipse Radio Pty. (ID = 950867) Radio
Monarch BKL; Eclipse Radio Pty. (ID = 950869) Radio Monarch BKL; Eclipse Radio Pty. (ID = 2312254) Radio
Use red slider bar for more.
Monarch BKL; Eclipse Radio Pty. (ID = 2313633) Radio
Eclipse Radio Pty.: Monarch BKL [Radio] ID = 2313633 1184x836
Select picture or schematic to display from thumbnails on the right and click for download.
For model Monarch BKL, Eclipse Radio Pty. Ltd.; Melbourne

Country:  Australia
Manufacturer / Brand:  Eclipse Radio Pty. Ltd.; Melbourne
alternative name

Electronic Industries Ltd
Year: 1946 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 6A8G 6B8G 6V6GT 5Y3G
Main principle Superheterodyne (common); ZF/IF 455 kHz; 1 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 200-220; 220-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: Monarch BKL - Eclipse Radio Pty. Ltd.;
Material Bakelite case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 290 x 170 x 180 mm / 11.4 x 6.7 x 7.1 inch
Circuit diagram reference Australian Official Radio Service Manual Vol. V
Literature/Schematics (1) Mingay's Radio Diagram & I.F. Index

Model page created by Stuart Irwin. See "Data change" for further contributors.



All listed radios etc. from Eclipse Radio Pty. Ltd.; Melbourne
Here you find 222 models, 54 with images and 111 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.


Collection of a member from AUS
