Peter Pan BPR

Peter Pan BPR; Eclipse Radio Pty. (ID = 2005895) Radio

Peter Pan BPR; Eclipse Radio Pty. (ID = 2005896) Radio

Peter Pan BPR; Eclipse Radio Pty. (ID = 2005897) Radio

Peter Pan BPR; Eclipse Radio Pty. (ID = 2005898) Radio

Peter Pan BPR; Eclipse Radio Pty. (ID = 2005899) Radio
Peter Pan BPR; Eclipse Radio Pty. (ID = 2499984) Radio Peter Pan BPR; Eclipse Radio Pty. (ID = 2499985) Radio
Peter Pan BPR; Eclipse Radio Pty. (ID = 2499986) Radio
Use red slider bar for more.
Peter Pan BPR; Eclipse Radio Pty. (ID = 2499984) Radio
Eclipse Radio Pty.: Peter Pan BPR [Radio] ID = 2499984 1400x982
Select picture or schematic to display from thumbnails on the right and click for download.
For model Peter Pan BPR, Eclipse Radio Pty. Ltd.; Melbourne

Country:  Australia
Manufacturer / Brand:  Eclipse Radio Pty. Ltd.; Melbourne
alternative name

Electronic Industries Ltd
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1T4 1R5 1T4 1S5 3V4
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 2 x 45 & 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out 0.1 W (0.25 W max.)
from Radiomuseum.org Model: Peter Pan BPR - Eclipse Radio Pty. Ltd.;
Shape Portable set > 8 inch (also usable without mains)
Notes

Battery consumption:

A Battery 300mA
B Battery 12.7mA (no signal)

See also Astor model PR & Pye model APR.

Circuit diagram reference Australian Official Radio Service Manual Vol. X

Model page created by Stuart Irwin. See "Data change" for further contributors.
