Multi-Signal Tracer 145-K

Multi-Signal Tracer 145-K; EICO Electronic (ID = 229050) Equipment
Use red slider bar for more.
Multi-Signal Tracer 145-K; EICO Electronic (ID = 229050) Equipment
EICO Electronic: Multi-Signal Tracer 145-K [Equipment] ID = 229050 191x151
Select picture or schematic to display from thumbnails on the right and click for download.
For model Multi-Signal Tracer 145-K, EICO (Electronic Instrument Co.Inc.) Brooklyn

Country:  United States of America (USA)
Manufacturer / Brand:  EICO (Electronic Instrument Co.Inc.) Brooklyn
Year: 1956 Category: Service- or Lab Equipment
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110-130 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: Multi-Signal Tracer 145-K - EICO Electronic Instrument Co.
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 10 x 8 x 4.75 inch / 254 x 203 x 121 mm
Notes Tracing IF, RF, video and audio circuits.
Price in first year of sale 20.00 $
Literature/Schematics (1) Allied Radio Catalog Nº 150, 1956

Model page created by Vitor Oliveira. See "Data change" for further contributors.
