For model Vacuum-Tube Voltmeter Kit 232-K, EICO (Electronic Instrument Co.Inc.) Brooklyn:
ebay: kajoa #320105486014

Country:  United States of America (USA)
Manufacturer / Brand:  EICO (Electronic Instrument Co.Inc.) Brooklyn
Year: 1956 Category: Service- or Lab Equipment
Valves / Tubes 2: 12AU7 6AL5
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110-130 & 1,5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Vacuum-Tube Voltmeter Kit 232-K - EICO Electronic Instrument Co.
Material Metal case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 5 x 7 x 4 inch / 127 x 178 x 102 mm
Notes

Range:
AC-/DC- Volts 1,5 - 5 - 15 -50 - 150 - 500 - 1500V
Resistance: 1 - 10 - 100 -1k - 10k - 100k - 1M x scale (1 ... 1000)

Price in first year of sale 30.00 $
Source of data -- Schematic
Literature/Schematics (1) Allied Radio Catalog Nº 150, 1956

Model page created by Vitor Oliveira. See "Data change" for further contributors.
