Oscilloscope Kit 460-K

Oscilloscope Kit 460-K; EICO Electronic (ID = 281090) Equipment

Oscilloscope Kit 460-K; EICO Electronic (ID = 281092) Equipment
Oscilloscope Kit 460-K; EICO Electronic (ID = 989692) Equipment Oscilloscope Kit 460-K; EICO Electronic (ID = 228894) Equipment
Oscilloscope Kit 460-K; EICO Electronic (ID = 949292) Equipment Oscilloscope Kit 460-K; EICO Electronic (ID = 949293) Equipment
Oscilloscope Kit 460-K; EICO Electronic (ID = 949294) Equipment Oscilloscope Kit 460-K; EICO Electronic (ID = 949295) Equipment
Oscilloscope Kit 460-K; EICO Electronic (ID = 949296) Equipment Oscilloscope Kit 460-K; EICO Electronic (ID = 1580782) Equipment
Oscilloscope Kit 460-K; EICO Electronic (ID = 1787311) Equipment Oscilloscope Kit 460-K; EICO Electronic (ID = 1787312) Equipment
Use red slider bar for more.
Oscilloscope Kit 460-K; EICO Electronic (ID = 989692) Equipment
EICO Electronic: Oscilloscope Kit 460-K [Equipment] ID = 989692 608x932
Select picture or schematic to display from thumbnails on the right and click for download.
For model Oscilloscope Kit 460-K, EICO (Electronic Instrument Co.Inc.) Brooklyn:
Eico_460_showing_calibrator_sinewave

Country:  United States of America (USA)
Manufacturer / Brand:  EICO (Electronic Instrument Co.Inc.) Brooklyn
Year: 1956 Category: Service- or Lab Equipment
Valves / Tubes 10: 6AU8 6AU8 6CB6 6CB6 12AU7 6J6 6J6 6AX5 1V2 5UP1 or DG13-32
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Oscilloscope Kit 460-K - EICO Electronic Instrument Co.
Material Metal case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 8.5 x 16 x 13 inch / 216 x 406 x 330 mm
Notes Sweep frequencies: 10 cps to 100 kc.
Price in first year of sale 80.00 $
Literature/Schematics (1) Allied Radio Catalog Nº 150, 1956

Model page created by Vitor Oliveira. See "Data change" for further contributors.
