Electronic Keyer 717

Electronic Keyer 717; EICO Electronic (ID = 660132) Morse+TTY
Electronic Keyer 717; EICO Electronic (ID = 660130) Morse+TTY Electronic Keyer 717; EICO Electronic (ID = 1104507) Morse+TTY
Electronic Keyer 717; EICO Electronic (ID = 1104509) Morse+TTY Electronic Keyer 717; EICO Electronic (ID = 1104510) Morse+TTY
Electronic Keyer 717; EICO Electronic (ID = 1104511) Morse+TTY Electronic Keyer 717; EICO Electronic (ID = 1104512) Morse+TTY
Use red slider bar for more.
Electronic Keyer 717; EICO Electronic (ID = 660130) Morse+TTY
EICO Electronic: Electronic Keyer 717 [Morse+TTY] ID = 660130 933x672
Select picture or schematic to display from thumbnails on the right and click for download.
For model Electronic Keyer 717, EICO (Electronic Instrument Co.Inc.) Brooklyn

Country:  United States of America (USA)
Manufacturer / Brand:  EICO (Electronic Instrument Co.Inc.) Brooklyn
Year: 1966 Category: Morse-Equipment & TTY, RTTY, TDD etc.
Valves / Tubes 6: 12AU7 12AU7 12AU7 6CB6 ECH81 ECH81
Main principle 1 AF stage(s); none
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110-130 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
Power out
from Radiomuseum.org Model: Electronic Keyer 717 - EICO Electronic Instrument Co.
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 8 x 5.5 x 8.5 inch / 203 x 140 x 216 mm
Notes 2 silicon rectifiers in power supply, 4 neon lamps type NE-2E. Speed range 3-75wpm.
Net weight (2.2 lb = 1 kg) 9 lb (9 lb 0 oz) / 4.086 kg
Price in first year of sale 70.00 $

Model page created by Edmund H. Ramm. See "Data change" for further contributors.
