R-C Bridge & R-C-L Comparitor 965

R-C Bridge & R-C-L Comparitor 965; EICO Electronic (ID = 2122478) Equipment R-C Bridge & R-C-L Comparitor 965; EICO Electronic (ID = 2122479) Equipment
R-C Bridge & R-C-L Comparitor 965; EICO Electronic (ID = 2122481) Equipment
Use red slider bar for more.
R-C Bridge & R-C-L Comparitor 965; EICO Electronic (ID = 2122478) Equipment
EICO Electronic: R-C Bridge & R-C-L Comparitor 965 [Equipment] ID = 2122478 1209x907
Select picture or schematic to display from thumbnails on the right and click for download.
For model R-C Bridge & R-C-L Comparitor 965, EICO (Electronic Instrument Co.Inc.) Brooklyn

Country:  United States of America (USA)
Manufacturer / Brand:  EICO (Electronic Instrument Co.Inc.) Brooklyn
Year: 1964 Category: Service- or Lab Equipment
Valves / Tubes 6: 6EJ7 12AX7 12AU7 0A2 6V4 6BX7GT
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: R-C Bridge & R-C-L Comparitor 965 - EICO Electronic Instrument Co.
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 320 x 220 x 200 mm / 12.6 x 8.7 x 7.9 inch
Notes

An extremely flexible, low voltage resistance-capacitance bridge and resistance-capacitance-inductance comparator, plus a capacitance leakege analyzer usable also for diode reverse and transistor quiescent current measurement and insulation testing.

It incorporates a 6-range DC VTVM and an 11-range DC VTAM (vacuum-tube ammeter)  that are externally usable. The DC VTAM has a voltage drop across the terminals of only 75mV, and a remarkable lowest range pf 0.15uA (150 nanoamps).

The meter is electronically protected in all functions and cannot be overloaded more than 200%.

Net weight (2.2 lb = 1 kg) 15 lb 0 oz (15 lb) / 6.810 kg
Literature/Schematics (1) -- Original-techn. papers.
Literature/Schematics (2) -- Schematic

Model page created by Daniel Barbitta. See "Data change" for further contributors.
