Tube & Transistor-Tester Deluxe 666

Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 1694829) Equipment
Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 1811415) Equipment Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 703181) Equipment
Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 703179) Equipment Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 703182) Equipment
Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 703183) Equipment Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 947826) Equipment
Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 980673) Equipment Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 1151723) Equipment
Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 1151724) Equipment Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 1151725) Equipment
Use red slider bar for more.
Tube & Transistor-Tester Deluxe 666; EICO Electronic (ID = 1811415) Equipment
EICO Electronic: Tube & Transistor-Tester Deluxe 666 [Equipment] ID = 1811415 1184x976
Select picture or schematic to display from thumbnails on the right and click for download.
For model Tube & Transistor-Tester Deluxe 666, EICO (Electronic Instrument Co.Inc.) Brooklyn:
aus ebay, #171673971153, Verkäufer pflavs

Country:  United States of America (USA)
Manufacturer / Brand:  EICO (Electronic Instrument Co.Inc.) Brooklyn
Year: 1956 ? Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 105-130 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Tube & Transistor-Tester Deluxe 666 - EICO Electronic Instrument Co.
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 380 x 115 x 380 mm / 15 x 4.5 x 15 inch
Notes

Tests all receiving tubes (and picture tubes with adapter)

Checks n-p-n & p-n-p transistors
Separate meter readings of collector leakage current and Beta.

Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Collectors' prices
Literature/Schematics (1) Selezione Radio-TV Marzo 1963

Model page created by Eduard Abfalterer. See "Data change" for further contributors.



All listed radios etc. from EICO (Electronic Instrument Co.Inc.) Brooklyn
Here you find 156 models, 151 with images and 87 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
EICO Electronic: Tube & Transistor-Tester Deluxe 666
Threads: 1 | Posts: 6
Hits: 2285     Replies: 5
eico: 666; Tube & Transistor-Tester Deluxe
Richard Fraser
16.Oct.14
  1 I have purchased an Eico 666,I am cleaning and testing this unit. I have read some modifications for this unit, diodes mounted to the meter leads. Would this be a good modification and can they be mounted to the wires other end away from the meter? Seems it would be easier then mounting directly to meter connections. Would there be any other mods to make for durability and reliability? All information would be appreciated. Richard
Rik Line
16.Oct.14
  2 Richard, I'm having trouble adding a link so Google this: buying, restoring and calibrating an eico 666/667 You are looking for a document called restr666.txt and it usually comes up as the first hit. I'm not sure if you had seen this yet, but it's an excellent resource. Best, Rik w2rik
Richard Fraser
18.Oct.14
  3 Thanks Rik the information was what I needed I finished the tester, calibrated it and is working great. Richard
Rik Line
18.Oct.14
  4 Awesome! I'm glad that I was able to point you in the right direction! Best, Rik
Rik Line
18.Oct.14
  5 Richard, Send me an email and I will send you some tube data for the Eico 666 that someone was kind enough to pass on to me. w2rik[A*T]arrl.net Best, Rik
Vince Adams
27.Jun.15
  6

thanks for the tip's. i am in the market for one off Ebay. I'll chk the info right away

Vince Adams
