CR152

• Country
• Great Britain (UK)

• Manufacturer / Brand
• Ekco, E.K.Cole Ltd.; Southend-on-Sea

• Year
• 1954

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 145340

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• EAF42 ECH42 EAF42 EBC41 EL42 EZ41

• Main principle
• Superhet with RF-stage; ZF/IF 465 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: CR152 - Ekco, E.K.Cole Ltd.; Southend-

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 215 x 85 x 220 mm / 8.5 x 3.3 x 8.7 inch

• Notes

• 3 Pre-set stations. Separate power pack & speaker. Several versions made for specific makes of car, with suffixes C, F, G, P, PL etc. Suffix X indicates no LW.

  Ford Motor (Dagenham/Essex) fitted optionally sub-type /F for standard vehicles and sub-type /N for de-luxe models. These cars are Ford Anglia 100E, Ford Prefect 100E, Ford Escort 100E, Ford Squire 100E and 2 van types. This list is not limitative.

• Price in first year of sale
• 27.00 GBP

• Source of data
• -- Schematic

• Circuit diagram reference
• Radio and TV Servicing books (R&TVS) book

• Literature/Schematics (1)
• -- Schematic (Ford Motor-Dagenham-Essex, repair manual (1956) for new Anglia, new Prefect, Escort, Squire)

• Author
• Model page created by Keith Staines. See "Data change" for further contributors.
