For model All Electric Receiver M 23 AC, Ekco, E.K.Cole Ltd.; Southend-on-Sea

Country:  Great Britain (UK)
Manufacturer / Brand:  Ekco, E.K.Cole Ltd.; Southend-on-Sea
Year: 1932 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: PM24M AC/HL MS4B
Main principle TRF with regeneration
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: All Electric Receiver M 23 [AC] - Ekco, E.K.Cole Ltd.; Southend-
Material Bakelite case
Shape Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
Dimensions (WHD) 14 x 16 x 9.25 inch / 356 x 406 x 235 mm
Notes not to be confused with the similar looking RS2AC or RS2DC. Westinghouse C13 metal half-wave rectifier.
Source of data Radio! Radio!

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
