Balmoral FM PCF102-418, 428, 438, 448, 458
Electrohome (Dominion Industries, ex Phonola); Kitchener (Ontario)
- Country
- Canada
- Manufacturer / Brand
- Electrohome (Dominion Industries, ex Phonola); Kitchener (Ontario)
- Year
- 1950 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 174815
- - Manufacturers Literature
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superhet with RF-stage; ZF/IF 455/10700 kHz
- Tuned circuits
- 7 AM circuit(s) 7 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Balmoral FM PCF102-418, 428, 438, 448, 458 - Electrohome Dominion
- Shape
- Console with any shape - in general
- Notes
- Electrohome Balmoral PCF102-418, PCF102-428, PCF102-438, PCF102-448, PCF102-458 for 25 Hz - 60 Hz mains power, PCF102-418Z, PCF102-428Z, PCF102-438Z, PCF102-448Z, PCF102-458Z for 60 Hz only mains power;
AM: 540 - 1650 kHz,
FM: 88 - 108 MHz.
- Source of data
- - - Manufacturers Literature
- Literature/Schematics (1)
- Radio College of Canada (RCC) (Supplement 21 page 15, 16 and 18)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
