- Country
- Canada
- Manufacturer / Brand
- Electrohome (Dominion Industries, ex Phonola); Kitchener (Ontario)
- Year
- 1955 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 202640
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 10 W (15 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Concerto - Electrohome Dominion
- Shape
- Console with any shape - in general
- Notes
-
The Electrohome Concerto is a 6-tube console record player with built in Gerard model RC-80M record changer. For 25 or 60 Hz depending on nameplate rating.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (1956 supplement 37)
- Author
- Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
