Kassettenrecorder KDG-Ü

Kassettenrecorder KDG-Ü; Elektronik Gera, VEB (ID = 1241685) R-Player Kassettenrecorder KDG-Ü; Elektronik Gera, VEB (ID = 1241686) R-Player
Kassettenrecorder KDG-Ü; Elektronik Gera, VEB (ID = 1241687) R-Player Kassettenrecorder KDG-Ü; Elektronik Gera, VEB (ID = 1241703) R-Player
Kassettenrecorder KDG-Ü; Elektronik Gera, VEB (ID = 1458098) R-Player Kassettenrecorder KDG-Ü; Elektronik Gera, VEB (ID = 1657142) R-Player
Kassettenrecorder KDG-Ü; Elektronik Gera, VEB (ID = 1657144) R-Player Kassettenrecorder KDG-Ü; Elektronik Gera, VEB (ID = 1657145) R-Player
Kassettenrecorder KDG-Ü; Elektronik Gera, VEB (ID = 1657146) R-Player
Use red slider bar for more.
Kassettenrecorder KDG-Ü; Elektronik Gera, VEB (ID = 1241685) R-Player
Elektronik Gera, VEB: Kassettenrecorder KDG-Ü [R-Player] ID = 1241685 933x723
Select picture or schematic to display from thumbnails on the right and click for download.
For model Kassettenrecorder KDG-Ü, Elektronik Gera, VEB, (Ostd.) (D)

Country:  Germany
Manufacturer / Brand:  Elektronik Gera, VEB, (Ostd.) (D)
Year: 1985 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 11:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220/ 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: Kassettenrecorder KDG-Ü - Elektronik Gera, VEB, Ostd. D
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 200 x 128 x 58 mm / 7.9 x 5 x 2.3 inch
Notes Der Kassettenrecorder KDG-Ü basiert auf dem Mira des gleichen Herstellers und wurde speziell für den Gebrauch bei der NVA (Nationale Volksarmee) hergestellt.
Die technischen Daten entsprechen denen des Mira.
Die Stromversorgung kann über 4 Babyzellen, eingebautes Netzteil oder externe Niederspannungsstromversorgung von 6-7,5 Volt erfolgen.
Bestückung: 1IC; 11 Transistoren, 6 Dioden und 1 Selengleichrichter.
Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Source of data -- Original prospect or advert

Model page created by Michael Seiffert. See "Data change" for further contributors.
