• Country
• Germany

• Manufacturer / Brand
• Elektronik Stadtroda, PGH (Ostd.) (D)

• Year
• 1957

• Category
• Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter

• Radiomuseum.org ID
• 98477

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECC85 EF85 EF80 EAA91

• Main principle
• Superhet with RF-stage; ZF/IF 10700 kHz

• Tuned circuits
• 9 FM circuit(s)

• Wave bands
• FM Broadcast Band Only

• Power type and voltage
• Powered by external power supply or a main unit. / 6,3 & DC 210-230 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Avanti UEG94W - Elektronik Stadtroda, PGH Ostd

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 95 x 60 mm / 7.1 x 3.7 x 2.4 inch

• Notes
• Enthält den UKW-Superspulensatz SSp222 der Firma Gustav Neumann.

• Net weight (2.2 lb = 1 kg)
• 0.5 kg / 1 lb 1.6 oz (1.101 lb)

• Source of data
• -- Collector info (Sammler)

• Mentioned in
• -- Original-techn. papers.

• Literature/Schematics (1)
• Funkverlag Hein, Service-DVD

• Author
• Model page created by Michael Seiffert. See "Data change" for further contributors.
