• Year
  • 1964
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 175982

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 200-250 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 3.5 W (unknown quality)
  • from Radiomuseum.org
  • Model: Automatic 2 - EAP Tape Recorders Ltd. -
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • Portable tape recorder fitted with BSR type TD2 deck. Single speed (3.75 ips), 2 track, max spool size 5.75 inches. Automatic recording level. Price 26gns.
  • Price in first year of sale
  • 27.00 GBP
  • Source of data
  • -- Schematic
  • Circuit diagram reference
  • Radio and TV Servicing books (R&TVS) book
  • Literature/Schematics (1)
  • Trader Sheet 1711
  • Author
  • Model page created by Keith Staines. See "Data change" for further contributors.
