Dorena 6402

Dorena 6402; Elektroakustik (ID = 100242) Radio

Dorena 6402; Elektroakustik (ID = 587163) Radio

Dorena 6402; Elektroakustik (ID = 587164) Radio

Dorena 6402; Elektroakustik (ID = 587165) Radio

Dorena 6402; Elektroakustik (ID = 587166) Radio

Dorena 6402; Elektroakustik (ID = 2125686) Radio
Dorena 6402; Elektroakustik (ID = 1391586) Radio Dorena 6402; Elektroakustik (ID = 1400425) Radio
Dorena 6402; Elektroakustik (ID = 1400426) Radio Dorena 6402; Elektroakustik (ID = 1400427) Radio
Dorena 6402; Elektroakustik (ID = 1400428) Radio Dorena 6402; Elektroakustik (ID = 1400429) Radio
Dorena 6402; Elektroakustik (ID = 1400430) Radio Dorena 6402; Elektroakustik (ID = 1400431) Radio
Dorena 6402; Elektroakustik (ID = 1695100) Radio Dorena 6402; Elektroakustik (ID = 222051) Radio
Use red slider bar for more.
Dorena 6402; Elektroakustik (ID = 1391586) Radio
Elektroakustik: Dorena 6402 [Radio] ID = 1391586 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Dorena 6402, Elektroakustik Hartmannsdorf, EAH, VEB(K), (Ostd.)

Country:  Germany
Manufacturer / Brand:  Elektroakustik Hartmannsdorf, EAH, VEB(K), (Ostd.)
Year: 1964/1965 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF121 AF135 AF137 AF138 GF122 GC117 GC116 AC128 AC128
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz; 3 AF stage(s)
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 2 x 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Dorena 6402 - Elektroakustik Hartmannsdorf,
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 285 x 180 x 85 mm / 11.2 x 7.1 x 3.3 inch
Notes

Diodenbuchse für TA/TB
Lautsprecherbuchse für Aussenlautsprecher
Oval-Lautsprecher 155 x 105 mm

Siehe auch Exportausführung TR 9Z mit UKW-Bereich bis 104 MHz.

Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
Price in first year of sale 500.00 DM
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Schematic

Model page created by Bernd Pötzsch. See "Data change" for further contributors.
