FM521; Erres, Van der Heem (ID = 372421) Converter

FM521; Erres, Van der Heem (ID = 372422) Converter

FM521; Erres, Van der Heem (ID = 372423) Converter

FM521; Erres, Van der Heem (ID = 372424) Converter

FM521; Erres, Van der Heem (ID = 372426) Converter

FM521; Erres, Van der Heem (ID = 372427) Converter

FM521; Erres, Van der Heem (ID = 372428) Converter

FM521; Erres, Van der Heem (ID = 372429) Converter

FM521; Erres, Van der Heem (ID = 372430) Converter

FM521; Erres, Van der Heem (ID = 372431) Converter
FM521; Erres, Van der Heem (ID = 372640) Converter FM521; Erres, Van der Heem (ID = 372641) Converter
FM521; Erres, Van der Heem (ID = 372642) Converter
Use red slider bar for more.
FM521; Erres, Van der Heem (ID = 372640) Converter
Erres, Van der Heem: FM521 [Converter] ID = 372640 640x252
Select picture or schematic to display from thumbnails on the right and click for download.
For model FM521, Erres, Van der Heem NV; Den Haag

Country:  Netherlands
Manufacturer / Brand:  Erres, Van der Heem NV; Den Haag
Year: 1952 Category: Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
Valves / Tubes 5: EF80 ECC81 EF80 EF80 EB91
Main principle Superhet with RF-stage; ZF/IF 17000 kHz
Tuned circuits 9 FM circuit(s)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: FM521 - Erres, Van der Heem NV; Den
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 330 x 120 x 60 mm / 13 x 4.7 x 2.4 inch
Notes FM unit for building into Erres receivers KY525, KY5265 and KY529
Net weight (2.2 lb = 1 kg) 1.9 kg / 4 lb 3 oz (4.185 lb)
Source of data - - Manufacturers Literature
Literature/Schematics (1) -- Original-techn. papers.

Model page created by John Hupse † 28.9.20. See "Data change" for further contributors.
