- Country
- Netherlands
- Manufacturer / Brand
- Erres, Van der Heem NV; Den Haag
- Year
- 1955
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 88383
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 453 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 127/220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: KY550 - Erres, Van der Heem NV; Den
- Shape
- Tablemodel with Clock ((Alarm-) Clock Radio).
- Dimensions (WHD)
- 374 x 192 x 131 mm / 14.7 x 7.6 x 5.2 inch
- Notes
- Radio mit Elektro-Uhr.
- Net weight (2.2 lb = 1 kg)
- 3.5 kg / 7 lb 11.3 oz (7.709 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by Paolo Tobia. See "Data change" for further contributors.
