• Year
  • 1933
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 268674

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); 1 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC) / 200; 230; 250 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: 5-Valve Super 5MS - Essanay Manufacturing Co. Pty
  • Shape
  • Chassis only or for «building in»
  • Notes
  • Advertised in the Essanay Super Het. Manual, 1933.

  • Mentioned in
  • Essanay Super Het. Manual, 1933.
  • Literature/Schematics (1)
  • HRSA Radiowaves, October 1995, Page 18
  • Author
  • Model page created by Gary Cowans. See "Data change" for further contributors.
