• Country
• Australia

• Manufacturer / Brand
• Essanay Manufacturing Co. Pty Ltd.; Melbourne

• Year
• 1937

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 268617

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• EK2 EBF1 EL3 EZ2

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 1 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Bantam 80 - Essanay Manufacturing Co. Pty

• Shape
• Tablemodel, with any shape - general.

• Notes

• Advertised in "The Age" newspaper 9 January 1937 for Aus£ 10/10/-

• Price in first year of sale
• 10.10 Aus£

• Mentioned in
• HRSA Radio Waves July 2001

• Author
• Model page created by Gary Cowans. See "Data change" for further contributors.
