Audion 475

Audion 475; Eumig, Elektrizitäts (ID = 810409) Radio Audion 475; Eumig, Elektrizitäts (ID = 493116) Radio
Use red slider bar for more.
Audion 475; Eumig, Elektrizitäts (ID = 810409) Radio
Eumig, Elektrizitäts: Audion 475 [Radio] ID = 810409 330x346
Select picture or schematic to display from thumbnails on the right and click for download.
For model Audion 475, Eumig, Elektrizitäts und Metallwaren-Industrie-Gesellschaft mbH; Wien:
Detailbild aus Quelle: Radiowelt Februar 1925 von Herrn Josef Pils

Country:  Austria
Manufacturer / Brand:  Eumig, Elektrizitäts und Metallwaren-Industrie-Gesellschaft mbH; Wien
Year: 1924/1925 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 1:
Main principle TRF with regeneration
Tuned circuits 1 AM circuit(s)
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Audion 475 - Eumig, Elektrizitäts und
Material Wooden case, TUBES VISIBLE.
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb


All listed radios etc. from Eumig, Elektrizitäts und Metallwaren-Industrie-Gesellschaft mbH; Wien
Here you find 253 models, 218 with images and 173 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
