ES-59

ES-59; Europhon; Milano (ID = 1191675) Radio
ES-59; Europhon; Milano (ID = 931206) Radio ES-59; Europhon; Milano (ID = 931207) Radio
ES-59; Europhon; Milano (ID = 931208) Radio ES-59; Europhon; Milano (ID = 931209) Radio
ES-59; Europhon; Milano (ID = 931210) Radio
Use red slider bar for more.
ES-59; Europhon; Milano (ID = 931206) Radio
Europhon; Milano: ES-59 [Radio] ID = 931206 800x484
Select picture or schematic to display from thumbnails on the right and click for download.
For model ES-59, Europhon; Milano

Country:  Italy
Manufacturer / Brand:  Europhon; Milano
Year: 1959/1960 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6BQ7A 6AJ8 6BA6 6T8 35D5 35A3
Main principle Superheterodyne (common); ZF/IF 460 kHz
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 3 W (unknown quality)
from Radiomuseum.org Model: ES-59 - Europhon; Milano
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 310 x 190 x 130 mm / 12.2 x 7.5 x 5.1 inch
Notes Consumo 35W.

Power consumption 35 watt.

Model page created by Angelo Viscardi. See "Data change" for further contributors.
