For model Unknown, Fairbanks, Morse & Co.; Chicago (IL)

Country:  United States of America (USA)
Manufacturer / Brand:  Fairbanks, Morse & Co.; Chicago (IL)
alternative name

FMC
Brand
Welco
Year: 1936 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6D6 6A7 6D6 6B7 43 25Z5
Main principle Superhet with RF-stage
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16.5 cm = 6.5 inch
Power out
from Radiomuseum.org Model: Unknown - Fairbanks, Morse & Co.;
Material Wooden case
Shape Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
Dimensions (WHD) 275 x 350 x 210 mm / 10.8 x 13.8 x 8.3 inch
Notes

Based on the tubes this may be either a Model 61, 6210 or 6244.

Net weight (2.2 lb = 1 kg) 5.7 kg / 12 lb 8.9 oz (12.555 lb)

Model page created by José Manuel Silvestre. See "Data change" for further contributors.
