411M Regency Series 400M

411M Regency Series 400M; Farnsworth (ID = 1310443) Radio

411M Regency Series 400M; Farnsworth (ID = 1310444) Radio

411M Regency Series 400M; Farnsworth (ID = 1310445) Radio

411M Regency Series 400M; Farnsworth (ID = 1310446) Radio

411M Regency Series 400M; Farnsworth (ID = 1310448) Radio

411M Regency Series 400M; Farnsworth (ID = 1310449) Radio

411M Regency Series 400M; Farnsworth (ID = 1310450) Radio

411M Regency Series 400M; Farnsworth (ID = 1310451) Radio

411M Regency Series 400M; Farnsworth (ID = 1310452) Radio

411M Regency Series 400M; Farnsworth (ID = 1310453) Radio
411M Regency Series 400M; Farnsworth (ID = 1317916) Radio 411M Regency Series 400M; Farnsworth (ID = 1310337) Radio
411M Regency Series 400M; Farnsworth (ID = 1310341) Radio 411M Regency Series 400M; Farnsworth (ID = 1310345) Radio
Use red slider bar for more.
411M Regency Series 400M; Farnsworth (ID = 1317916) Radio
Farnsworth: 411M Regency Series 400M [Radio] ID = 1317916 933x817
Select picture or schematic to display from thumbnails on the right and click for download.
For model 411M Regency Series 400M, Farnsworth Television & Radio Corp. - see also Capehart:
From a eBay picture, sold 05/28/2011, taken by WorthPoint. I heavily worked on the perspective - but it is still only 'better than nothing'.

Country:  United States of America (USA)
Manufacturer / Brand:  Farnsworth Television & Radio Corp. - see also Capehart
Year: 1941/1942 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 31: 6AB7 6SA7 6J5 6SG7 6AF6G 6SG7 6SJ7 6SN7 6SJ7 6B8 6H6 6SN7 6Q7 6R7 6C8G 6V6G 6V6G 6V6G 6V6G 5Y3G 5Y3G 5Y3G 6R7 6C8G 6V6G 6V6G 6V6G 6V6G 5Y3G 5Y3G 5Y3G
Main principle Superhet with RF-stage; ZF/IF 455/4300 kHz
Wave bands Broadcast, 2 Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 105 - 125 Volt
Loudspeaker 2 Loudspeakers
Power out 40 W (unknown quality)
from Radiomuseum.org Model: 411M Regency Series 400M - Farnsworth Television & Radio
Material Wooden case
Shape Console with any shape - in general
Notes

Dual power amplifier, dual electrodynamic speakers 12" and 13.5", the latter called type M20.
Record Changer Capehart16-E. Details have to be cleared. Note: BC/SW/ and old FM on a modern slide rule dial with green tuning eye. 2 amplifier chassis employing 4 push-pull parrallel 6V6 output tubes each. The radio also features the impressive capehart flip over changer. original wood and screen backs and two doors which open in the front to expose the dual speakers.
The first sets with a number about below 20 000 used pot metal parts which will in the meantime in most cases be destroyed.
See here the "Common information for the Capehart model pages for the 1930s and 1940s" and for the information about Series 400 here.



External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 19 = 1949 and before
Mentioned in The Incomparable Capehart
Literature/Schematics (1) Rider's Perpetual, Volume 20 = covering 1950


All listed radios etc. from Farnsworth Television & Radio Corp. - see also Capehart
Here you find 393 models, 278 with images and 321 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
