• Year
  • 1939
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 201996
    • Brand: TRF

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 470 kHz
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • AC/DC-set / 200-250 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Radiogram 902U - Ferguson Brand, Ferguson Radio
  • Shape
  • Console with Push Buttons.
  • Notes
  • Push buttons for four pre-set radio stations, waveband changing and gramophone switching. See also the Ferguson 902 Radiogram AC mains version.
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
