• Country
• Great Britain (UK)

• Manufacturer / Brand
• Ferguson (Brand), Ferguson Radio Corporation Ltd., British Radio Corporation Ltd.; London

• Year
• 1968

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 303652

• • Brand: TRF

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• ECC83 ECL86 ECC82

• Number of Transistors
• 1

• Semiconductors
• SE1002

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 230-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 3 W (unknown quality)

• Material
• Various materials

• from Radiomuseum.org
• Model: Tape Recorder 3238 - Ferguson Brand, Ferguson Radio

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Dimensions (WHD)
• 16.5 x 14.5 x 7 inch / 419 x 368 x 178 mm

• Notes

• 4 tracks (can be paired on playback) 3 speed (7.5, 3.75 and 1.875 ips) mono tape recorder. Maximum spool diameter 7 inch. Moving coil meter. Automatic stop. Remote pause. Tape monitoring. Input mixing. Digital counter. Similar to the Marconiphone 4238 tape recorder.

• Mentioned in
• ERT Service chart 1731 dated January 1970

• Author
• Model page created by Howard Craven. See "Data change" for further contributors.
