Funküberwachungs-Messempfänger CE30

• Country
• Austria

• Manufacturer / Brand
• Fernmeldetechnisches Zentralamt, Wien

• Year
• 1952

• Category
• Commercial Receiver (may include amateur bands)

• Radiomuseum.org ID
• 155842

• Picture
• Schematics

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes
• EF42 ECH42 EAF42 EBC41 EL41 EZ2/3 1910 RG15/150

• Main principle
• Superhet with RF-stage; ZF/IF 1585 kHz; 2 AF stage(s); none

• Tuned circuits
• 10 AM circuit(s)

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Line / Batteries (any type) / 110-240 / ? Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case, TUBES VISIBLE

• from Radiomuseum.org
• Model: Funküberwachungs-Messempfänger CE30 - Fernmeldetechnisches

• Shape
• Tablemodel, low profile (big size).

• Notes
• Röhren nur 1x je Typ aufgeführt. Frequenzbereich 2-30 MHz in 6 Bereichen. Spulenrevolver.

• Source of data
• -- Schematic

• Author
• Model page created by Rudolf Müller. See "Data change" for further contributors.
