Stella 1102; Stern-Radio Staßfurt (ID = 1658621) Television
Stern-Radio Staßfurt: Stella 1102 [Television] ID = 1658621 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stella 1102, Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...

Country:  Germany
Manufacturer / Brand:  Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...
alternative name

Fernsehgerätewerk Staßfurt
Year: 1968/1969 Category: Television Receiver (TV) or Monitor
Valves / Tubes 13: PCC88 PCF82 EF183 EF184 PFL200 PCL86 ECC82 PCL85 PCF802 PL500 PY88 DY86 B59G2
Semiconductors (the count is only for transistors) 1: GF139
Main principle Superheterodyne (common); ZF/IF 38900 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Stella 1102 - Stern-Radio Staßfurt, VEB, RFT
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes Das Modell Stella 1102 ist ein Gerät der Standardkonzeption II. Der Kaskodetuner empfängt die Kanäle 2 bis 12, der DF- Verstärker ist mit einem Transistor GF139 aufgebaut. Das Gerät ist zur Nachrüstung mit einem UHF- Tuner vorbereitet. Als Bildröhre ist die implosionsgeschützte B59G2 eingebaut.
Source of data -- Original prospect or advert
Literature/Schematics (1) Service-DVD Funkverlag B. Hein

Model page created by Andreas Hahn. See "Data change" for further contributors.
