Fera V500
Fernseh-Radio Berlin (FERA), PGH; (Ostd)
- Country
- Germany
- Manufacturer / Brand
- Fernseh-Radio Berlin (FERA), PGH; (Ostd)
- Year
- 1989
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 100072
aus admin.de
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 32
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 100 W (170 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Fera V500 - Fernseh-Radio Berlin FERA, PGH
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 436 x 98 x 250 mm / 17.2 x 3.9 x 9.8 inch
- Notes
-
HiFi-Stereoverstärker. Nachfolger des Fera 150. Sinusausgangsleistung 2× 50 W, Übertragungsbereich 20...20.000 Hz. 4 Ausgänge, davon 2× für Pseudoquattrobetrieb; 5 Eingänge, Anwahl über Drehschalter.
In der DDR erfolgte der Verkauf ab 1989, Exportmodelle bereits ab 1984. Eisenlose Endstufe mit je 2 Stück 2N3055 (Tungsram).
Transistoren nur einmal angeführt.
- Net weight (2.2 lb = 1 kg)
- 7 kg / 15 lb 6.7 oz (15.419 lb)
- Price in first year of sale
- 980.00 DM
- Author
- Model page created by Wolfgang Lill. See "Data change" for further contributors.
