Transistor Seven Portable Receiver 199

Fidelity Radio Co. Ltd.; London

Data

Forum

Pictures

Collections

Country
Great Britain (UK)

Manufacturer / Brand
Fidelity Radio Co. Ltd.; London

Year
1965 ??

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
255599

Schematics

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 2568388) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (1)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 2568391) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (1)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 2568389) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (1)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 2568390) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (1)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699052) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699054) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1696558) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699041) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699043) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699044) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699045) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699046) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699048) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699049) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699050) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699051) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Transistor Seven Portable Receiver 199; Fidelity Radio Co. (ID = 1699053) Radio — Fidelity Radio Co. Transistor Seven Portable Receiver 199 (2)

Technical Specifications

Number of Transistors
7

Semiconductors
AF117 AF117 AF117 OC71 OC81D OC81 OC81

Main principle
Superheterodyne (common); ZF/IF 470 kHz

Tuned circuits
5 AM circuit(s)

Wave bands
Broadcast (MW) and Long Wave.

Power type and voltage
Dry Batteries / PP6; 1 x 9 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: Transistor Seven Portable Receiver 199 - Fidelity Radio Co. Ltd.;

Shape
Very small Portable or Pocket-Set (Handheld) < 8 inch.

Dimensions (WHD)
180 x 113 x 45 mm / 7.1 x 4.4 x 1.8 inch

Notes
Made in England.

Author
Model page created by a member from A. See "Data change" for further contributors.
