• Year
  • 1939
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 101568
    • Brand: Ambassador

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • TRF (Tuned-Radio-Frequency but use of regeneration unknown); 3 AF stage(s)
  • Tuned circuits
  • 2 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC) / 200-250 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 10 W (unknown quality)
  • from Radiomuseum.org
  • Model: Ambassador PA143 - Ambassador brand, R. N. Fitton
  • Notes
  • PA amplifier with radio unit. Similar to model PA142 except it has continues tuning.
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by Peter Hoddow. See "Data change" for further contributors.
